Description
Deep Squeegee Cleaning
Equipped with 100W ultrasonic cleaning and a 65°C hot water system, it thoroughly cleans the squeegee, preventing streaks and secondary contamination.
Deep Brush Cleaning
Upon task completion, the robot docks automatically, and its roller brush is deeply cleaned to remove over 95% of adhered debris and avoid leftover dirt.
Coordinates with CC1 Pro’s Detection
CC1 Pro detects secondary contamination and automatically docks for squeegee cleaning before resuming work, creating a seamless loop: Detect → Dock → Self-Clean → Resume.
Up to 35× Maintenance Efficiency Boost
The robot automatically cleans its squeegee and roller brush, eliminating the need for frequent manual maintenance.
Three-in-One Models, Freely Combined
One product, three forms — Docking Station, Self-Cleaning Docking Station, and Self-Cleaning Docking Station Pro, ready for any scenario.
Modular Quick-Release Design
Quick-release brush cleaning assembly and squeegee tank allow one person to easily handle maintenance.
Basic specifications
Supports auto charging; auto filling & drainage; auto detergent filling; automatic cleaning of the squeegee and roller brush for CC1 Series robots
Product Dimensions (L×W×H):
– Docking Station: 374 × 618 × 546 mm (14.72 × 24.33 × 21.50 in)
– Self-Cleaning Docking Station: 632 × 715 × 571 mm (24.88 × 28.15 × 22.48 in)
– Self-Cleaning Docking Station Pro: 1013 × 715 × 571 mm (39.88 × 28.15 × 22.48 in)
Product Weight:
– Docking Station: 25 kg (55.12 lb)
– Self-Cleaning Docking Station: 35 kg (77.16 lb)
– Self-Cleaning Docking Station Pro: 41 kg (90.39 lb)
Input Voltage: 100–240 Vac
Output Voltage: 29.2 Vdc
Working Temperature: 0–40°C
Working Humidity: ≤ 90% (at 40°C)
Storage Temperature: −20–70°C
Communication Method: Bluetooth
Installation Requirements: Floor-anchored or backed against a wall
External Dependencies: Water supply, floor drain, power supply; Mobile Water Station (optional)
Get a Custom Quote
Ready to get started? Request a personalized quote for the Pudu Self-Cleaning Docking Station.
